VS Series HMI

Unique Futures:-

Carry high-performance industrial
Cortex-A8 processor, main frequency can be up to 600MHz
Improve data processing efficiency greatly
Built-in COM port is integrated with RS232/422/485 communication modes
Support industrial Ethernet communication, realize data exchange among multiple devices via built-in 10M/100M self-adaptive network card Support free port communication protocol
Abundant built-in vectorgram library
Support customized vectorgram
Provide standard outline for common vectorgram
Support macro instruction programming, C language script
Support U-disk update and data import/export
PC can communicate with PLC directly via HMI
Support two HMIs to communicate simultaneously with one PLC
Online simulation function, PC can be connected to PLC directly to simulate configuration project
Alarm record memory can be expanded
Industry-level design enables stable operation
High-capacity FLASH, power-off memory, support U-disk storage
New password system which is safer and more reliable
